Supplementary material to C. Gische and M. C. Voelkle, “Beyond the Mean: A Flexible Framework for Studying Causal Effects Using Linear Models,” Psychometrika, (2021). https://doi.org/10.1007/s11336-021-09811-z.
Beyond the Mean: A Flexible Framework for Studying Causal Effects Using Linear Models
Beyond the Mean: A Flexible Framework for Studying Causal Effects Using Linear Models
Christian Gische
Define the matrix of structural coefficients and the covariance matrix of the error terms
Define the matrix of structural coefficients and the covariance matrix of the error terms
(*definethematrixofstructuralcoefficients;sincethesymbolCisprotectedinMathematica,welabelthematrixasC6,where6isthenumberofobservedvariables*)
In[]:=
C6={{0,0,0,0,0,0},{0,0,0,0,0,0},{cxx,cxy,0,0,0,0},{cyx,cyy,0,0,0,0},{0,0,cxx,cxy,0,0},{0,0,cyx,cyy,0,0}};
(*definethecovariancematrixoftheerrorterms*)
In[]:=
PSI={{psix1x1,psix1y1,psix1x2,0,0,0},{psix1y1,psiy1y1,0,psiy1y2,0,0},{psix1x2,0,psixx,psixy,psix2x3,0},{0,psiy1y2,psixy,psiyy,0,psiy2y3},{0,0,psix2x3,0,psixx,psixy},{0,0,0,psiy2y3,psixy,psiyy}};
(*definethemeanvectoroftheerrorterms*)
In[]:=
Eepsilon={{0},{0},{0},{0},{0},{0}};
Compute the model implied distribution of observed variabels
Compute the model implied distribution of observed variabels
(*definethemodelimpliedmeanvectoroftheobservedvariables*)
In[]:=
EV=Inverse[IdentityMatrix[6]-C6].Eepsilon;
(*definethemodelimpliedcovariancematrixoftheobservedvariables*)
In[]:=
SigmaV=Inverse[IdentityMatrix[6]-C6].PSI.Transpose[Inverse[IdentityMatrix[6]-C6]];
(*collecttermsinthemodelimpliedcovariancematrixoftheobservedvariables*)
In[]:=
SigmaV=Collect[SigmaV,{psix1x1,psiy1y1,psix1y1,psixx,psiyy,psixy,psix1x2,psix2x3,psiy1y2,psiy2y3}];
(*extractthemodelimpliedvarianceofX2*)
In[]:=
VX2=SigmaV[[3,3]];
(*extractthemodelimpliedvarianceofY3*)
In[]:=
VY3=SigmaV[[6,6]];
(*extractthemodelimpliedcovarianceofX2andY3*)
In[]:=
COVX2Y3=SigmaV[[3,6]];
(*calculatetheconditionalmeanofY3givenX2=x2*)
In[]:=
EY3condX2=COVX2Y3/VX2*x2;
(*calculatetheconditionalvarianceofY3givenX2=x2*)
In[]:=
VY3condX2=VY3-(COVX2Y3^2/VX2);
Calculate the interventional moments for do(X2=x2)
Calculate the interventional moments for do(X2=x2)
(*definetheselectionmatrixfortheinterventionalvariable*)
In[]:=
e3={{0},{0},{1},{0},{0},{0}};
(*definethematrixthatsetstheinterventionalrowtozero*)
In[]:=
IN={{1,0,0,0,0,0},{0,1,0,0,0,0},{0,0,0,0,0,0},{0,0,0,1,0,0},{0,0,0,0,1,0},{0,0,0,0,0,1}};
(*definethetransformationmatrixT1*)
In[]:=
T1=Inverse[IdentityMatrix[6]-IN.C6].IN;
(*definethevectora1*)
In[]:=
a1=Inverse[IdentityMatrix[6]-IN.C6].e3;
(*calculatetheinverventionalmeanvector*)
In[]:=
Edox2=a1*x2;
(*calculatetheinverventionalcovariancematrix*)
In[]:=
Vdox2=T1.PSI.Transpose[T1];
(*collecttermsinthemodelimpliedcovariancematrixoftheobservedvariables*)
In[]:=
Vdox2=Collect[Vdox2,{psix1x1,psiy1y1,psix1y1,psixx,psiyy,psixy,psix1x2,psix2x3,psiy1y2,psiy2y3}];
(*extracttheinterventionalmeanofY3givendo(X2=x2)*)
EY3dox2=Edox2[[6]];
(*extracttheinterventionalvarianceofY3givendo(X2=x2)*)
VY3dox2=Vdox2[[6,6]];
ProofofIdentification
(*matrixofstructuralcoefficientsaccordingtoEquation3.2.1inBekkeretal.(1994);thismatrixcorrespondstothematrixI-Cfromthepaper;seealsoTableS.3ofthiselectronicsupplementarymaterial*)
In[]:=
IminusC6={{1,0,0,0,0,0},{0,1,0,0,0,0},{-cxx,-cxy,1,0,0,0},{-cyx,-cyy,0,1,0,0},{0,0,-cxx,-cxy,1,0},{0,0,-cyx,-cyy,0,1}};
(*CovariancematrixoferrortermsaccordingtoBekkeretal.(1994);thismatrixcorrespondstothematrixPsifromthepaper;seealsoTableS.3ofthiselectronicsupplementarymaterial*)
In[]:=
Psi={{psix1x1,psix1y1,psix1x2,0,0,0},{psix1y1,psiy1y1,0,psiy1y2,0,0},{psix1x2,0,psixx,psixy,psix2x3,0},{0,psiy1y2,psixy,psiyy,0,psiy2y3},{0,0,psix2x3,0,psixx,psixy},{0,0,0,psiy2y3,psixy,psiyy}};
(*restrictionmatrixR_PsiseeEquation(S.31)ofthiselectronicsupplementarymaterial*)
In[]:=
RPsi={{0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,-1,0,0,0,0,0,0,0},{0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,-1},{0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,-1,0,0,0,0,0,0}};
In[]:=
Dimensions[RPsi]
(*restrictionmatrixR_CseeEquation(S.32)ofthiselectronicsupplementarymaterial*)
In[]:=
In[]:=
Dimensions[RC]
(*commutationmatrixform=n=6,seeEquation1.5.1inBekkeretal.(1994)*)
In[]:=
(*M-matrix,seeSection1.5(belowEquation1.5.1)inBekkeretal.(1994)forp=6*)
In[]:=
M6=1/2*(IdentityMatrix[36]+K6);
(*Kroneckerproductinthefirstentryofthematrixontheright-handsideofEquation3.3.6inBekkeretal.(1994);seealsoEquation(S.29)ofthiselectronicsupplementarymaterial*)
In[]:=
FPsi=KroneckerProduct[IdentityMatrix[6],Psi];
(*Firstentryofthematrixontheright-handsideofEquation3.3.6inBekkeretal.(1994)seealsoEquation(S.29)ofthiselectronicsupplementarymaterial*)
In[]:=
J1=2*RPsi.M6.FPsi;
(*Kroneckerproductinthesecondentryofthematrixontheright-handsideofEquation3.3.6inBekkeretal.(1994);seealsoEquation(S.29)ofthiselectronicsupplementarymaterial*)
In[]:=
FC=KroneckerProduct[IdentityMatrix[6],Transpose[IminusC6]];
(*Secondentryofthematrixontheright-handsideofEquation3.3.6inBekkeretal.(1994);seealsoEquation(S.29)ofthiselectronicsupplementarymaterial*)
In[]:=
J2=RC.FC;
(*Joinfirstandsecondentryofthematrixontheright-handsideofEquation3.3.6inBekkeretal.(1994)toobtaintheJacobianmatrix;seealsoEquation(S.29)ofthiselectronicsupplementarymaterial*)
In[]:=
J=Join[J1,J2];
(*RankevaluationoftheJacobianmatrix*)
In[]:=
MatrixRank[J]
Out[]=
36
In[]:=
NullSpace[J]
Out[]=
{}
In[]:=
Dimensions[J]
Out[]=
{43,36}
